Highly reliable equipment, especially designed for high viscosity products
Vertical design with center discharge, jacketed for heating purposes, optional mounted on 3 load-cells
Counter-rotating double-stirring type mixer, with optimal height-diameter ratio for mixing
Outer stirrer executed with wall-scrapers for self-cleaning of the tank and advanced mixing possibilities
Easy cleaning and for that reason quick product changes

Description

The performance of pre-mixing is getting more and more important. To ensure the best performances of the downstream processes (i.e. ball mill) and for that reason the best product quality, an optimal and homogeneous mixing of the basic materials is a “must”. In a liquid batch mixer it is important that all solid particles are equally surrounded by liquid particles to ensure lowest possible viscosities during further processing. Only the well-proven design based on counter-rotating mixing principle ensures just this.
Each unit can handle at least 1 batch per hour (depending on product feeding rate), which ensures enough mixing time after ingredient dosing for a homogenous liquid paste. Ingredients that are used in chocolate or compound are highly viscous, meaning that mixing equipment used must have enough torque in order to thoroughly mix the various ingredients, and on industrial scale even in large batches.
Royal Duyvis Wiener can supply several type of batch mixers that are well-designed for this challenge. Each executed with 2 heavy-duty helical geared motors, designed in several batch sizes.
The outer stirrer is always executed with spring-loaded wall- and bottom scrapers for self-cleaning of the internal tank and advanced mixing possibilities. Even re-mixing of segregated sugar is possible after temporary stopping.
