Technical advantages:
1.It can squeeze a variety of raw materials.
2.Three-section press chamber ,higher output,faster oil output.
3.The
oil press is not restricted by the climate and is suitable for all
seasons in the east,west,south,and north. Because the oil pan device
adopts a heating control system, it can automatically adjust the
temperature of the crude oil according to the ambient temper to achieve
the effect of rapid fine filtration.
4.The body is equipped with a
vacuum filtration system,which increases the capacity and easily filters
the oil without repeated operations.
5.The design is scientific,the
structure is reasonable ,the operation is simple,the operation is safe
and stable,and the fully automatic device is adopted.It only takes a few
minutes from feeding to finished product at one time.
Type | YZYX30 | YZYX70 | YZYX125 | YZYX150 | YZYX168 | YZYX208 |
Motor power(kw) | 1.5 | 4 | 15 | 22 | 30 | 37 |
Voltage(v) | 220 | 380 | 380 | 380 | 380 | 380 |
Hourly capacity(kg/h) | 15-20 | 40-50 | 120-150 | 230-280 | 300-350 | 350-400 |
Size(length x width x height in mm) | 700*700*1000 | 1000*1000*1250 | 1750*1550*1700 | 2600*1800*1800 | 2600*1800*1800 | 2600*1800*1800 |
Total weight(kg) | 145 | 256 | 920 | 1200 | 1700 | 1700 |
